X-TAR VC4 Charger
  • X-TAR VC4 Charger
  • X-TAR VC4 Charger
  • X-TAR VC4 Charger

X-TAR VC4 Charger

£24.99

The XTAR VC4 is a e-cigarette battery charger which combines intelligent design and safety to provide with a truly high level device.

Quantity
There are not enough products in stock

By buying this product you can collect up to 99 loyalty points. Your cart will total 99 points that can be converted into a voucher of £0.99.

  • PayPal secures all payments PayPal secures all payments
  • Orders before 2pm shipped same day Orders before 2pm shipped same day

The XTAR VC4 charger is a combination of our XP4C and VC2 charger. This intelligent charger can recognize, charge, and display charging current, battery voltage, and charge capacity of both Ni-MH and Li-ion batteries at the same time. This is a USB powered charger so it can be plugged into any of your existing AC USB wall adapter plugs (e.g. Apple, Samsung, etc.)

Does not include batteries.

Lithium battery charging parameter:

  • Input Power DC 5.0V 2.1A
  • 0.5A CC Current 500±50m A
  • 1.0A CC Current 1000±80m A
  • Cut-off Voltage 4.20±0.05V
  • Operation Temperature 0-40℃

Ni-MH battery charging parameter:

  • Input Power DC 5.0V 2.1A
  • 0.5A Pulse Charging Current 500±50 mA
  • 1.0A Pulse Charging Current 1000±80 mA
  • Cut-off Voltage 1.45±0.1V
  • Operation Temperature 0-40℃

Note: There is a protective sticker on all charger screens and it may appear to be scratched when you receive it. Don’t worry, simply remove this sticker to see the actual screen.

The charger makes an estimate of how much the battery has taken in mAh, this is what it has put in the battery and does not account for anything that was already in there, it also does not know how the battery will react on discharge, while this charger give some information that is to some degree useful, it is not giving you a absolute true reading of battery capacity. The only way to do this is by applying a load on the battery at a constant current and monitoring as it discharges.

H8-005

Data sheet

Battery Charger Slots
Quad
